Portable spectrum analyzer Anritsu MS2090A-0726 (9 kHz – 26.5 GHz)
Product code: 1020011
From 799 002 UAH
Main characteristics
-
Manufacturer:Anritsu (Japan, USA) Official representative
-
Category:
-
Series:
-
Spectrum analysis:9 kHz – 26.5 GHz
-
Spectrum analyzer type:Swept-tuned Real-time
-
Signal analysis bandwidth:20 MHz 50 MHz 100 MHz
-
Real-time analysis bandwidth:22 MHz 55 MHz 110 MHz
-
Maximum amplitude:+30 dBm
-
Average noise DANL:-161 dBm -164 dBm
-
SSB phase noise:-106 dBc/Hz -110 dBc/Hz
-
Antenna analysis:150 kHz – 6 GHz
-
RF power measurement:10 MHz – 26 GHz
-
Operating temperature:From -10°С to +55°С
-
Width:314 mm
-
Height:235 mm
-
Depth:95 mm
-
Weight:5.4 kg
Product description
Anritsu MS2090A-0726 is a professional portable spectrum analyzer with a frequency range of 9 kHz – 26.5 GHz and a large set of additional features. In addition to the classic spectrum analysis, the following are available when the appropriate options are installed: real-time analysis (with a bandwidth of 22 MHz, 55 MHz or 110 MHz), vector signal analysis, search for interference sources, mapping coverage areas, channel scanner, 5G analyzer, LTE analyzer, WCDMA analyzer, pulse analyzer, electromagnetic field meter, high-precision power meter, antenna analyzer and much more.
The Anritsu MS2090A-0726 analyzer is part of the Anritsu MS2090A series. It is designed in a robust portable case with a large touch screen. Connection to a computer is carried out using Ethernet (LAN), Wi-Fi or USB interfaces. The standard capabilities of the Anritsu MS2090A-0726 can be expanded with additional options and accessories, which are listed below on this page in the relevant sections.
For more information about this product, see the Anritsu MS2090A series pageContents of delivery
- handheld spectrum analyzer Anritsu MS2090A-0726 (1 pc.)
- Li-ion battery (installed inside the analyzer) (1 pc.)
- soft case for carrying the analyzer (1 pc.)
- external power supply (1 pc.)
- Ethernet cable, 2 meters (1 pc.)
- USB cable, 1 meter (1 pc.)
- cable SMA(m) - BNC(m), 1 meter (1 pc.)
- adapter SMA(m) - BNC(f) (3 pcs.)
- stylus (1 pc.)
- user manual in electronic form
- calibration certificate
- 1 year warranty
