Dual-range DC power supply ITECH IT6874A, 150 V, 1.2 A, 180 W or 60 V, 2 A, 120 W

Main characteristics

• Manufacturer:
  ITECH (Taiwan) Official representative
• Category:
  Laboratory power supplies
• Series:
  ITECH IT6800AB
• Output voltage type:
  Direct current (DC)
• Number of channels (DC):
  1
• Maximum output voltage (DC):
  150 V 60 V
• Maximum output current (DC):
  1.2 A 2 A
• Maximum output power (DC):
  180 W 120 W
• Voltage resolution (DC):
  1 mV 10 mV
• Current resolution (DC):
  0.1 mA
• Operating principle:
  Linear
• 4-wire sensing:
  Yes
• Protection modes:
  Short circuit protection Current protection (OCP) Voltage protection (OVP, UVP) Temperature protection (OTP)
• Built-in devices:
  Multimeter (DMM)
• Peculiarities:
  Adjustable Stabilized Precision Programmable
• Connection to computer:
  USB RS-232
• Operating temperature:
  From 0°С to +40°С
• Width:
  215 mm
• Height:
  88 mm
• Depth:
  355 mm
• Weight:
  8.5 kg
