Powerful laboratory power supply ITECH IT6726C, 32 V, 220 A, 3 000 W

ITECH IT6700H series typical high voltage laboratory power supply (3000 W)
Typical power supply of the ITECH IT6700H series (3000 W, back view)
ITECH IT6700H series typical high voltage laboratory power supply (3000 W)
Typical power supply of the ITECH IT6700H series (3000 W, back view)
On order

Product code: 3020146

From 121 392 UAH

Main characteristics

  • Manufacturer:
    ITECH (Taiwan) Official representative
  • Category:
    Laboratory power supplies
  • Series:
    ITECH IT6700H
  • Output voltage type:
    Direct current (DC)
  • Number of channels (DC):
    1
  • Maximum output voltage (DC):
    32 V
  • Maximum output current (DC):
    220 A
  • Maximum output power (DC):
    3 000 W
  • Voltage resolution (DC):
    10 mV
  • Current resolution (DC):
    10 mA
  • Operating principle:
    Switching
  • 4-wire sensing:
    Yes
  • Protection modes:
    Voltage protection (OVP, UVP) Current protection (OCP) Temperature protection (OTP) Short circuit protection
  • Built-in devices:
    Multimeter (DMM)
  • Peculiarities:
    Adjustable Stabilized Powerful Programmable
  • Connection to computer:
    USB GPIB (IEEE-488.2) RS-232
  • Operating temperature:
    From 0°С to +40°С
  • Width:
    483 mm
  • Height:
    99 mm
  • Depth:
    601 mm
  • Weight:
    16 kg

Product description

ITECH IT6726C is a powerful laboratory power supply with output voltage up to 32 V and current up to 220 A. The maximum power supplied to the load reaches 3 000 W. The IT6726C power supply has a list mode (up to 150 steps), all types of overload protection and the ability to connect in a 4-wire circuit for increased accuracy at high current.

To connect to a computer, the ITECH IT6726C laboratory power supply contains USB, IEEE-488 and RS-232 interfaces. Remote control can be performed using a free program or use the driver for LabVIEW, which can be downloaded below on this page in the Documentation section. Model IT6726C is part of the ITECH IT6700H series.

For more information about this product, see the ITECH IT6700H series page

Contents of delivery

  • powerful laboratory power supply ITECH IT6726C (1 pc.)
  • USB cable (1 pc.)
  • power cable (1 pc.)
  • user manual in electronic form
  • calibration certificate
  • 1 year warranty
