General information

Micsig Technology manufactures premium portable oscilloscopes, including 12-bit models, multi-channel models, tablet oscilloscopes, USB oscilloscopes and other types. In addition to a wide range of portable oscilloscopes, Micsig manufactures a variety of voltage and current probes for oscilloscopes, including isolated probe models.

Micsig company product catalog (34 pages; 6 MB)

Micsig MHO6 – eight-channel oscilloscopes up to 1 GHz

Micsig MHO6 series oscilloscope
Micsig MHO6 series of eight-channel oscilloscopes up to 1 GHz.

The Micsig MHO6 series are portable 8-channel oscilloscopes with 350 MHz, 500 MHz, and 1 GHz bandwidth, 6 GS/s sample rate, and 1 800 M points of internal memory. Micsig MHO6 oscilloscopes provide high-quality signal processing with 12-bit hardware resolution and the ability to measure up to 280 000 waveforms per second. All models feature a large 406 mm touchscreen with a resolution of 1920 × 1200 pixels, while the thickness of the case is only 35 mm.

Main characteristics of Micsig MHO6 series models
Model
Bandwidth
Analog channels
Sample rate
Record length
Waveforms per second
Vertical resolution
Weight
Novelty
Top sales
MHO68-350
350 MHz 8 6 GS/s 1 800 M points 280 000 12 bits 5.7 kg
Novelty
MHO68-500
500 MHz 8 6 GS/s 1 800 M points 280 000 12 bits 5.7 kg
Novelty
Top sales
MHO68-1000
1 GHz 8 6 GS/s 1 800 M points 280 000 12 bits 5.7 kg

Description and characteristics of the Micsig MHO6 series (3 pages; 2 MB)

Micsig MHO3 – four-channel oscilloscopes up to 500 MHz

Micsig MHO3 series oscilloscope
Micsig MHO3 series of four-channel oscilloscopes up to 500 MHz.

The Micsig MHO3 series are portable 4-channel oscilloscopes with 250 MHz, 350 MHz, and 500 MHz bandwidth, 3 GS/s sample rate, and 360 M points of internal memory. Micsig MHO3 oscilloscopes provide high-quality signal processing with 12-bit hardware resolution and the ability to measure up to 230 000 waveforms per second. The MHO3 series has a noise level of less than 80 µV RMS at full bandwidth, allowing accurate measurement of even the weakest signals.

All models feature a large 355 mm touchscreen with a resolution of 1920 × 1200 pixels, while the thickness of the case is only 36 mm and its weight is 4.3 kg.

Main characteristics of Micsig MHO3 series models
Model
Bandwidth
Analog channels
Sample rate
Record length
Waveforms per second
Vertical resolution
Weight
MHO3-2504
250 MHz 4 3 GS/s 360 M points 230 000 12 bits 4.3 kg
MHO3-3504
350 MHz 4 3 GS/s 360 M points 230 000 12 bits 4.3 kg
Top sales
MHO3-5004
500 MHz 4 3 GS/s 360 M points 230 000 12 bits 4.3 kg

Description and characteristics of the Micsig MHO3 series (9 pages; 3 MB)

Micsig MHO1 – tablet oscilloscopes up to 200 MHz

Micsig MHO1 series oscilloscope
Micsig MHO1 series of tablet oscilloscopes up to 200 MHz.

The Micsig MHO1 series are four-channel tablet oscilloscopes with 100 MHz and 200 MHz bandwidth, 1 GS/s sample rate, and 110 M points of internal memory. Micsig MHO1 oscilloscopes provide high-quality signal processing with 12-bit hardware resolution and the ability to measure up to 50 000 waveforms per second. All models feature a large 203 mm touchscreen with a resolution of 1280 × 800 pixels, while the thickness of the case is only 31 mm.

Micsig MHO1 oscilloscopes can operate both from the mains and from the built-in battery. All models of the series contain a hardware frequency counter with a resolution of 6 digits, and two models MHO14-100 and MHO14-200 contain a built-in multimeter with a resolution of 4.5 digits.

Main characteristics of Micsig MHO1 series models
Model
Bandwidth
Analog channels
Sample rate
Record length
Waveforms per second
Vertical resolution
Weight
Novelty
MHO14-100
100 MHz 4 1 GS/s 110 M points 50 000 12 bits 1.73 kg
Novelty
MHO14-100N
100 MHz 4 1 GS/s 110 M points 50 000 12 bits 1.69 kg
Novelty
Expert's choice
MHO14-200
200 MHz 4 1 GS/s 110 M points 50 000 12 bits 1.73 kg
Novelty
Top sales
MHO14-200N
200 MHz 4 1 GS/s 110 M points 50 000 12 bits 1.69 kg

Description and characteristics of the Micsig MHO1 series (10 pages; 5 MB)

Description and characteristics of models N of the Micsig MHO1 series (9 pages; 4 MB)

Micsig TO – tablet oscilloscopes up to 300 MHz

Micsig TO series oscilloscope
Micsig TO series of tablet oscilloscopes up to 300 MHz.

The Micsig TO series are tablet oscilloscopes with 100 MHz, 200 MHz and 300 MHz bandwidth, sampling rate up to 2 GS/s and internal memory up to 220 M points. The speed of continuous waveform acquisition and analysis reaches 300 000 waveforms per second. Micsig TO oscilloscopes can operate both from the mains and from the built-in battery. All models of the series are equipped with a touch screen with a diagonal of 256 mm and a resolution of 1280 × 800 pixels, while the thickness of the case is 50 mm, and the weight is 1.9 kg.

Main characteristics of Micsig TO series models
Model
Bandwidth
Analog channels
Sample rate
Record length
Waveforms per second
Vertical resolution
Weight
TO1004
100 MHz 4 1 GS/s 110 M points 78 000 8 bits 1.9 kg
TO2002
200 MHz 2 1 GS/s 110 M points 78 000 8 bits 1.9 kg
TO2004
200 MHz 4 2 GS/s 220 M points 300 000 8 bits 1.9 kg
TO3004
300 MHz 4 2 GS/s 220 M points 300 000 8 bits 1.9 kg

Description and characteristics of the Micsig TO series (10 pages; 2 MB)

Micsig SATO – automotive oscilloscopes up to 200 MHz

Micsig SATO series oscilloscope
Micsig SATO series of automotive oscilloscopes up to 200 MHz.

The Micsig SATO series are tablet automotive oscilloscopes with 100 MHz and 200 MHz bandwidth, sampling rate up to 1 GS/s and internal memory up to 70 M points. The speed of continuous waveform acquisition and analysis reaches 130 000 waveforms per second. Micsig SATO oscilloscopes can operate both from the mains and from the built-in battery. All models of the series are equipped with a touch screen with a diagonal of 203 mm and a resolution of 800 × 600 pixels, while the thickness of the case is 50 mm, and the weight is 1.9 kg.

Micsig SATO oscilloscopes can be used to perform a complete check of any type of vehicle. For this purpose, they contain pre-installed sets of settings for typical auto diagnostic tasks, including analysis of CAN, LIN, FlexRay and K-Line protocols. The set of probes that these oscilloscopes are equipped with is optimized for connection to various vehicle units. With the help of Micsig SATO, you can test the ignition system, generator, starter, various sensors and auxiliary systems of the vehicle.

Main characteristics of Micsig SATO series models
Model
Bandwidth
Analog channels
Sample rate
Record length
Waveforms per second
Vertical resolution
Weight
SATO1004
100 MHz 4 1 GS/s 70 M points 130 000 8 bits 1.9 kg
SATO2002
200 MHz 2 1 GS/s 70 M points 130 000 8 bits 1.9 kg

Description and characteristics of the Micsig SATO series (8 pages; 2 MB)
