Optical reflectometer module up to 45 dB for EXFO trunks FTB-7500E
Product code: 1000799
Check availability DiscontinuedAdd item to cart. Our specialist will coordinate with you the complete set, tell you the price and delivery time.
Price on request
Out of production. Recommended replacement: EXFO FTBx-750C
MAIN CHARACTERISTICS
The EXFO FTB-7500E OTDR long-haul optical reflectometer module is designed for measurements in backbone optical networks. The combination of a wide dynamic range (up to 45 dB) and a small dead zone (0.8 m for events, 4 m for attenuation) makes the modules indispensable for testing backbone FOCLs and FTTP networks.
Allows you to test networks with speeds up to 40 Gb / s.
Additionally, the module can be equipped with the VFL option, a visual fault locator, which makes it an extremely flexible and cost-effective instrument.
FTB-7500 E optical reflectometer modules are compatible with measurement platforms: EXFO FTB-500 and EXFO FTB-200.
Specifications of EXFO FTB-7500E Optical Reflectometer Modules
Modifications of EXFO FTB7500E optical reflectometer modules
- FTB-7500E-0023B-XX-VFL SM OTDR Module, 1310/1550 nm, 45/43 dB (9/125 µm)
- FTB-7500E-0034B-XX-VFL SM OTDR Module, 1550/1625 nm, 45/ 45dB (9/125µm)
Warranty:
1 year. It is possible to extend the warranty period up to 3 years.
Description of the optical reflectometer module for EXFO FTB-7500E trunks (14 pages; 4.5 MB)
